POWER CLAMP NANO NG i4.0   Horizontal i4.0 shrink fit machine for tool holders and shrink fit collets.

Optional

Clips for tools (optional) For safest and precise handling of high quality carbide tools - especially with smaller diameters

Calibration adapter for length presetting (Optional) For resetting the measuring device

Power Clamp Nano NG i4.0 is especially suitable for small tool holders in high frequency spindles, for shrink fit collets and for shrink fit chucks up to SK40/HSK-A63.

• Easy tool handling by horizontal shrinking.
• With intelligent motor coil.
• With scanner to readout shrinking parameters from tool holders (Data-Matrix code).
• With air cooling for tools from Ø 3-32 mm
• With 7"-Touch-Display and new intuitive software.
• Industry 4.0-ready due to scanner connection.
• Power : 13kW
• Mains voltage : 3x400 - 480 V, 16A
• Tools: solid carbide and HSS form Ø 3-32 mm
